Generators
Jialing Gasoline Generator Set — B Series
The B-series generator sets are manufactured by China Jialing Industry Co., Ltd. (Group) — a state-controlled listed company under China South Industries Group, with a national-level technology center, postdoctoral research station, five domestic manufacturing bases, four overseas subsidiaries and an annual capacity of one million units. Certified to ISO 9001 / ISO 14001 / CCC. The JL B-series spans 2.8kW portable units to 9.8kW three-phase ETS sets, covering both 220V single-phase and 380V three-phase needs, with 14.5–25 L fuel tanks for home backup, shop standby, jobsite power and small event use.
Main Technical Features
- 2.8–9.8 kW output across 7 models
- 220 V single-phase and 380 V three-phase ETS options
- Large 14.5–25 L fuel tanks for continuous running
- Recoil or electric start available
- ISO 9001 / ISO 14001 / CCC certified, 1 million units annual capacity
Technical Parameters
JL-B Series Technical Specifications
| Model | JL3500-B | JL6500-B | JL8500-B | JL9000ETS-B | JL10000-B | JL12000ETS-B | JL13000ETS-B |
|---|---|---|---|---|---|---|---|
Displacement | 211 ml | 420 ml | 420 ml | 439 ml | 439 ml | 499.7 (194) ml | 499.7 (194) ml |
Power | 2.8~3.0 kW | 5.0~5.5 kW | 6.5~7.0 kW | 7.5~8.4 kW | 8.0~10.0 kW | 8.0~9.1 kW | 8.5~9.8 kW |
Rated Current | 12.1 A | 21.7 A | 28.3 A | — | 34.8 A | 38.6 / 12.9 A | 36.9 / 16.2 A |
Fuel Consumption | 2.0 L/h | 3.0 L/h | 3.2 L/h | 3.5 L/h | 3.5 L/h | 3.5 L/h | 3.5 L/h |
Fuel Tank | 14.5 L | 25 L | 25 L | 25 L | 25 L | 25 L | 25 L |
Dimensions | 595×440×450 mm | 700×515×580 mm | 700×515×580 mm | 700×515×580 mm | 700×515×580 mm | 695×515×595 mm | 695×515×595 mm |
Net Weight | 47.6 / 49 kg | 82.1 / 84 kg | 86.5 kg | 88.5 kg | 96 kg | 92.8 kg | 94.9 kg |
Starting | Recoil / Electric | Recoil / Electric | Recoil | Electric | Recoil | Electric | Electric |
