Shared E-Bikes
YADEA Q20 Shared E-Bike
The YADEA Q20 is a long-range shared e-bike with a 48V 20Ah/24Ah slim battery and a 350W motor, delivering about 70km of range at a capped speed of 25km/h. The 1570×665×1020mm frame features 27-tube hydraulic front suspension, front/rear 110 drum brakes, 16×2.5 solid tires, 4G connectivity with 485 protocol and LED lights. It is offered with either a standard basket or a smart helmet-detection basket to meet different operating standards. The slim battery and standardized seat-bucket dimensions simplify battery swapping and maintenance for large-scale city and scenic-area fleets.
Main Technical Features
- 48V 20/24Ah slim battery, 350W motor, about 70km range
- 27-tube hydraulic front suspension, front/rear 110 drum brakes, 16×2.5 solid tires
- 4G control unit with 485 protocol, speed capped at 25km/h
- LED front/rear lights; standard or smart helmet-detection basket
- Standardized seat-bucket dimensions for easy swapping and fleet maintenance
Technical Parameters
| Model | YADEA Q20 |
|---|---|
Dimensions L×W×H (mm) | 1570×665×1020 |
Wheelbase (mm) | 1085 |
Saddle height (mm) | 720 |
Tires | 16×2.5 solid tires |
Suspension | 27-tube hydraulic front / 27-tube hydraulic front |
Brakes | F&R 110 drum / F&R 110 drum |
Rear grab bar | Steel (standard) |
Battery | 48V20Ah / 48V24Ah slim battery |
Motor | 350W |
Controller | 18A current limit / 18A current limit |
Control unit | 4G |
Communication | RS-485 |
Riding speed | ≤25km/h |
Range | 70km |
Lights | LED |
Seat-bucket size (mm) | 180×133×285 / 180×110×325 |
Basket | Standard basket / smart helmet-detection integrated basket |
